Intelligent Krebs Stormer Viscometer

Comparing with BGD 184, it has these features as below:

◆ Can show “KU”, “cP”, “g”,  “℃” value simultaneously.

◆ Designed with calibration function: With standard oil, users can complete calibration independently, no need return it to manufacture.

◆ Biult in infrared thermometer sensor to measure sample temperature, more convenient and more precise.

◆ Has a big LCD which can show test result clearly

◆ Can set test time and show real time

◆ With RS 232 communication port, can print test results

◆ Self protection function under over-range.

◆ Magnetic rotor enables rapid installing, dismantlement or cleaning

◆ Come with Calibration Certificate

NOTE:

The cP reading from the Krebs Stormer Viscometer is not necessarily agree with cP values measured by other instruments due to:

1. Unique shear rate of the Krebs Stormer Viscometer paddle spindle.

2. Uniqueness of the Krebs unit scale

Main Technical Parameters

■ Range: 40.2KU～141.0KU     27-5,250 cP
■ Accuracy：±1.0% of full scale range
■ Repeatability：±0.5% of full scale range
■ Paddle Speed：200r/min±0.1r/min
■ Overall Dimensions：210mm×180mm×500mm（length by width by height ）

■ Package Size：560mm×450mm×280mm

■ Package Weight：9.2 KG

■ Ordering Information：BGD 186—Intelligent Krebs Stormer Viscometer

BGD 186/J-042–—Special Paddle for Paste

BGD 1600/Z-012—Standard Oil for Krebs Stormer Viscometer （67.2 KU）

BGD 1600/Z-013—Standard Oil for Krebs Stormer Viscometer （86.3 KU）

BGD 1600/Z-014—Standard Oil for Krebs Stormer Viscometer （106.6 KU）

BGD 1600/Z-015—Standard Oil for Krebs Stormer Viscometer （121.5 KU）

BGD 186 Intelligent Krebs Stormer Viscometer.pdf
