Provided to colleges, industrial and mining enterprises and scientific research departments for precise constant temperature and auxiliary heating.
◆ The housing is integrally molded with ABS material, resistant to acid, alkali, and corrosion;
◆ Seamless stainless steel inner tank with adjustable beaker hole size;
◆ High-precision microcomputer controller ensures precise and reliable temperature regulation;
◆ Over-temperature sound and light tracking alarm for reliable sample protection;
◆ Dry-burn protection (requires manual start/stop for reset) to prevent accidents;
◆ Five-button control eliminates risks associated with automatic restart;
◆ Lightweight design with optional independent temperature limit protection.
Main Technical Parameters
| Ordering Information → Technical Item ↓ | BGD 830 （1 column 2 hole） | BGD 831 （2 columns 4 holes） | BGD 832 （2 columns 6 holes） | BGD 833 （2 columns 8 holes） |
| Power Supply | AC220V 50HZ | |||
| Input Power | 500W | 1,000W | 1500W | 2,000W |
| Temperature Range | RT+5～99℃ | |||
| Temperature Stability | ±0.5℃ | |||
| Tracking Alarm | ±2℃ | |||
| Capacity | 5L | 10.8L | 24.8L | 24.8L |
| Inner Size（mm）W×D×H | 300×155×150 | 300×240×150 | 500×300×150 | 500×300×150 |
| Overall Size（mm）W×D×H | 345×210×280 | 345×295×280 | 550×360×280 | 550×360×280 |
| Timing Range | 0～5999min | |||
| Note | ① Each hole has 5 circles（Ф32、Ф52、Ф72、Ф92、Ф112） for BGD 830 and BGD 832； ② BGD 831 has 4 holes, two of them is 5 circles（Ф32、Ф52、Ф72、Ф92、Ф112）; the other two is 4 circles（Ф32、Ф52、Ф72、Ф92）； ③ GD 833 has 8 holes, four of them is 5 circles（Ф32、Ф52、Ф72、Ф92、Ф112）; the other four is 4 circles（Ф32、Ф52、Ф72、Ф92） ； | |||
